Description
Features
- Port monitoring
- System connection and management services
- Virtual Local Area Network (VLAN) configuration
- Spanning Tree Protocol (STP)/Rapid Spanning Tree Protocol (RSTP)
- Jumbo frame support
- Ping watchdog
- Configurable alerts
- 8 x 10/100/1000 Ethernet Data Ports
- 1 x 10/100 Ethernet Management Port
- MIPS 24K, 400 MHz Processor
- USB 2.0 Type A Port
- 64MB System Memory
- 8MB Code Storage
- 24V/48V Configurable Passive PoE
- PoE Configuration Interface
- Tough Full Metal & Rubber Casing
- CE, FCC, IC Certified
Specifications
|
Processor |
MIPS 24 K, 400 MHz |
|
USB Port |
USB 2.0 type A (reserved for future use) |
|
System Memory |
64 MB |
|
Code Storage |
8 MB |
|
PoE Method |
Passive |
|
Management Port |
1 x 10/100 Ethernet port |
|
Data Ports |
8 x 10/100/1000 Ethernet ports |
|
PoE Configurable Per Port |
Off/24 V/48 V |
|
Management Port |
Power/link/activity |
|
LEDs Per Port Data Ports |
PoE, speed/link/activity |
|
Power Input |
110 to 120 VAC/210 to 230 VAC |
|
Power Consumption |
Maximum: 150 W |
|
PoE Out-Voltage Range |
45 to 48 VDC/22 to 24 VDC |
|
Maximum PoE Wattage Per Data Port |
11.5 W (24 V), 23 W (48 V) |
|
ESD Rating |
Air: 24 kV |
|
Operating Temperature |
‑13 to +131°F (‑25 to +55°C) |
|
Operating Humidity |
90% (non-condensing) |
|
Certifications |
CE, FCC, IC |
|
Button |
Reset |
|
Dimensions |
8.2 x 7.2 x 1.6″ (210.0 x 185.0 x 41.0 mm) |
|
Weight |
2.73 lb (1.24 kg) |
